PD30S-BCS-GGG-C

ARO PD30S-BCS-GGG-C AODD Diaphragm Pump. Stainless Steel Air Motor / Air Cap, Cast Iron Fluid Caps & Manifold, Stainless Steel Hardware. Nitrile Seats, Nitrile Balls, Nitrile Diaphragm, Rp 3 (3 - 11 BSP parallel) Connection. An Ingersoll Rand Business.

Brand: ARO

Series:

3” Metallic Expert

Item: PD30S-BCS-GGG-C

Retail Price: $8,945.49

Ships within 1 business day (in-stock items). Delivery typically 1-5 business days.

Returns accepted within 30 days. View Returns Policy

Estimate Shipping

Zip Code

Overview

Literature & Manuals

Find the manuals, product sheets and all the information you need

Type	Title	Link
Brochures	Electronic Interface Brochure	View
Brochures	Expert Seriess Brochure	View
Data Sheets	PD30R PE30R 3" Metallic Datasheet	View
Data Sheets	PE30X-XXX-XXX-C0S 3" Metallic Datasheet	View
Installation & Operation Manuals	PD30R PE30R 3" Metallic Manual	View
Installation & Operation Manuals	PD30X PE30X 3" Metallic Manual	View
Installation & Operation Manuals	PE30X-XXX-XXX-C0S 3" Metallic Manual	View

Series Information

3” Metallic Expert Information

Features & Benefits
3” Metallic Performance Specifications Ratio: 1:1 Maximum GPM (LPM): 275 (1041) Displacement per cycle: 2.8 (10.6) @ 100 psi Gallons (Liters) Air Inlet: (Female) 3/4 - 14 N.P.T.F. - 1 Fluid Inlet / Outlet (Female): 3” - 8 N.P.T.F. - 1 Rp 3 (3 - 11 BSP parallel) Max. operating pressure psi (bar): 120 (8.3) Suspended solids max. dia. in. (mm): 3/8 (9.5) Weight lbs (kg): PX30A-XAX-XXX-C 129.5 (58.8) PX30A-XCX-XXX-C 216.6 (98.2) PX30A-XSX-XXX-C 228.8 (103.8) PX30A-XHX-XXX-C 249.8 (113.3) PX30R-XCX-XXX-C 242.3 (109.9) PX30R-XSX-XXX-C 253.3 (114.9) Note: Add 40 lbs (18.2 kg) for stainless steel air motor section Maximum dry suction lift ft (m): 14 (4.2) Sound Level: PSI Cycles / Min db(A) 70 50 83.0

Features & Benefits

3” Metallic Performance Specifications
Ratio: 1:1
Maximum GPM (LPM): 275 (1041)
Displacement per cycle: 2.8 (10.6)
@ 100 psi Gallons (Liters)
Air Inlet: (Female) 3/4 - 14 N.P.T.F. - 1
Fluid Inlet / Outlet (Female): 3” - 8 N.P.T.F. - 1
Rp 3 (3 - 11 BSP parallel)
Max. operating pressure psi (bar): 120 (8.3)
Suspended solids max. dia. in. (mm): 3/8 (9.5)
Weight lbs (kg): PX30A-XAX-XXX-C 129.5 (58.8)
PX30A-XCX-XXX-C 216.6 (98.2)
PX30A-XSX-XXX-C 228.8 (103.8)
PX30A-XHX-XXX-C 249.8 (113.3)
PX30R-XCX-XXX-C 242.3 (109.9)
PX30R-XSX-XXX-C 253.3 (114.9)
Note: Add 40 lbs (18.2 kg) for stainless steel air motor section
Maximum dry suction lift ft (m): 14 (4.2)
Sound Level:
PSI Cycles / Min db(A)
70 50 83.0
