DISCHARGE: Vertical .................... 2" NPT Flange ...................... 2"/2.50"/3", Horizontal
LIQUID TEMPERATURE .............. 104°F (40°C) Continuous
VOLUTE ....................................... Cast Iron ASTM A-48, Class 30
MOTOR HOUSING ....................... Cast Iron ASTM A-48, Class 30
SEAL PLATE ............................... Cast Iron ASTM A-48, Class 30
IMPELLER: Design ...................... 12 Vane,Vortex, With Pump Out Vanes On Back Side. Dynamically Balanced, ISO G6.3 Material ................... Cast Iron
SHREDDING RING ...................... Hardened 440C Stainless Steel, Rockwell® C-55
CUTTER ....................................... Hardened 440C Stainless Steel, Rockwell® C-55
SHAFT ......................................... 416 Stainless Steel
SQUARE RINGS .......................... Buna-N
HARDWARE ................................. 300 Series Stainless Steel
PAINT ........................................... Air Dry Enamel
SEAL: Design ..................... Tandem Mechanical, Oil Filled Reservoir Material .................... Rotating Faces - Carbon Stationary Faces - Ceramic Elastomer - Buna-N Hardware -300 Series Stainless
CORD ENTRY ............................... Custom Molded, Quick Connected for Sealing and Strain Relief
POWER CORD ............................. CSA Certified Submersible Power Cable 2000V
UPPER BEARING: Design ..................... Single Row, Ball, Oil Lubrication Load ........................ Radial
LOWER BEARING: Design ..................... Double Row, Ball, Oil Lubrication Load ......................... Radial & Thrust
MOTOR: Design ..................... NEMA B Three Phase Torque Curve Oil-Filled, Squirrel Cage Induction, Inverter Duty rated per NEMA MG1 Insulation.................. Class H Varnish & Magnet Wire
SINGLE PHASE ............................ Requires overload protection to be included in control panel. Requires start components to be included in panel. Provided with pump
THREE PHASE ............................. Requires overload protection to be included in control panel
MOISTURE SENSORS ................. Normally Open (N/O), Requires relay in control panel
TEMPERATUR SENSOR ........... Normally Closed (N/C) To be wired in series with control circuit
OPTIONAL EQUIPMENT .............. Seal Material, Impeller Trims, Cord Length, Leg Kit
