EP72X

Product features for superior performance
• Maximum flow rate to 90 GPM (EP72) and 83 GPM (EP52).
• Maximum shut off head of 31 ft.
• Stainless steel shaft and hardware provide excellent corrosion resistance.
• Permanent Split capacitor motor for reliable, high performance, longer motor life, greater starting torque, and lower amp draw.
• Interchangeable with other effluent pumps.

Design Options
• Vertical or tethered floats are easily adjusted for varying conditions.
• All switches come with standard 20’ cord.
• Manual models available if preferred.

Models - EP52X - EP72X
Motor - 1/2 hp - 3/4 hp
RPM - 3450
Electrical - 240v 1ph
Construction - Cast Iron
Discharge - 1.5"
Solids - .75"

Effluent / Sump Pump Series
Design Features
• Vortex impeller design provides ¾” spherical solids handling capability
• Upper and lower ball bearings are oil lubricated for maximum life
• Silicon carbide mechanical seal faces provide outstanding grit resistance
• Industrial-style motors, contained in a cast iron housing, are oil filled for optimum cooling and long life
• Pump provided with protective high temperature overload switch
• Unit provided with power cord including molded NEMA 6-15P plug for 230V single phase operation.
• Cast Iron vortex impeller
• CSA Listed
• 12 month limited warranty
