AV8HJS1V1C7001809

Name: AV8HJS1V1C7001809 PumpCatalog Finish Thompson FTI
Brand: Finish Thompson FTI
SKU: AV8HJS1V1C7001809
Price: 8820.00 USD
Availability: OutOfStock

Finish Thompson AV8HJS1V1C7001809, FTI AV Series Stainless Steel Vertical Pump, AV8H 1-1/4 x 3/4 NPT, 230-460 Volt, 3450 RPM, FKM O-Ring, 3 Phase, 7 1/2 HP, 7.00" Closed design impeller, 50-60 Hz, 120 psi, 106 GPM

Brand: Finish Thompson FTI

Series:

AV Vertical Metallic Centrifugal Pumps

Item: AV8HJS1V1C7001809

List: ~~$11,025.00~~

$8,820.00

Ships within 1 business day (in-stock items). Delivery typically 1-5 business days.

Returns accepted within 30 days. View Returns Policy

Estimate Shipping

Zip Code

Overview

Literature & Manuals

Find the manuals, product sheets and all the information you need

Type	Title	Link
Brochures	AC, AV, AK Series Pumps Brochure (2022)	View
Brochures	Chemical Processing Applications Flyer (2022)	View
Data Sheets	AC, AV, AK 6 & 8 Series Pumps Datasheet (2022)	View
Data Sheets	AP Series Series Pumps Performance Curves (2022)	View
Installation & Operation Manuals	AV6 AV8 Series Pumps Installation & Operation Manual (2022)	View

Series Information

AV Vertical Metallic Centrifugal Pumps Information

Features & Benefits
AV Series Typical Applications • Chemical processing • Plating, photo processing • Printed circuit boards • Pharmaceutical • Waste water treatment AV Vertical Metallic Centrifugal Pump Features: • Corrosion resistant 316 stainless steel • Close coupled • Back pull out design for easy service • Compact design with secure V-clamp (304 stainless steel) • Standard, recessed, or high head impellers • SS mounting plate for in-tank installation (AV models only) • FKM, EPDM, or carbon lower bushings (AV models only) • 1.8 specific gravity with no impeller trim • Maximum temperature: 300°F (149°C) • Maximum working pressure: 100 psi (6.9 bar)
General Description
AV Vertical Metallic Centrifugal Pumps are compact in design, easy to operate and handle, and economically priced. Built from high quality 316 stainless steel, these pumps are available in horizontal, vertical, or vertical cantilevered designs. All wetted parts are constructed of corrosion resistant materials to withstand the harshest chemical environments. The AP Series accept standard NEMA and IEC frame motors and feature standard NPT or BSP threaded ports with tri-clamp or flanges optional.

Popular Series

Series associated to this product and brand

Features & Benefits
AV Series Typical Applications • Chemical processing • Plating, photo processing • Printed circuit boards • Pharmaceutical • Waste water treatment AV Vertical Metallic Centrifugal Pump Features: • Corrosion resistant 316 stainless steel • Close coupled • Back pull out design for easy service • Compact design with secure V-clamp (304 stainless steel) • Standard, recessed, or high head impellers • SS mounting plate for in-tank installation (AV models only) • FKM, EPDM, or carbon lower bushings (AV models only) • 1.8 specific gravity with no impeller trim • Maximum temperature: 300°F (149°C) • Maximum working pressure: 100 psi (6.9 bar)
General Description
AV Vertical Metallic Centrifugal Pumps are compact in design, easy to operate and handle, and economically priced. Built from high quality 316 stainless steel, these pumps are available in horizontal, vertical, or vertical cantilevered designs. All wetted parts are constructed of corrosion resistant materials to withstand the harshest chemical environments. The AP Series accept standard NEMA and IEC frame motors and feature standard NPT or BSP threaded ports with tri-clamp or flanges optional.
