MSVKCP24CVVN15C

Name: MSVKCP24CVVN15C PumpCatalog Finish Thompson FTI
Brand: Finish Thompson FTI
SKU: MSVKCP24CVVN15C
Price: 2928.12 USD
Availability: OutOfStock

Finish Thompson FTI Pump End MSVKCP24CVVN15C Vertical Multistage Centrifugal, VKC Series Plastic Mag Drive, MSVKC, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.88" Impeller, 80 psi, 61 GPM

Brand: Finish Thompson FTI

Series:

MSVKC Vertical Multistage Mag Drive Pumps

Item: MSVKCP24CVVN15C

List: ~~$3,754.00~~

$2,928.12

Ships within 1 business day (in-stock items). Delivery typically 1-5 business days.

Returns accepted within 30 days. View Returns Policy

Estimate Shipping

Zip Code

Overview

Finish Thompson FTI Pump End MSVKCP24CVVN15C Vertical Multistage Centrifugal, VKC Series Plastic Mag Drive, MSVKC, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.88" Impeller, 80 psi, 61 GPM

Literature & Manuals

Find the manuals, product sheets and all the information you need

Type	Title	Link
Data Sheets	MSVKC Vertical Multistage Pumps Datasheet (2022)	View
Installation & Operation Manuals	MSVKC Vertical Pumps Installation & Operation Manual (2022)	View

Series Information

MSVKC Vertical Multistage Mag Drive Pumps Information

Features & Benefits
MSVKC Vertical Multi Stage Mag Drive Pumps Feature: • Sealless mag drive technology - eliminates microbubbles • Multi-Stage design: Generates increased head at low flow rates, low power consumption, wide hydraulic envelope allows for mix and match impeller sizes • Unique interconnecting drive shaft - transmits torque from magnetic coupling to first stage impeller • Independent thrust bearings at each stage for maximum reliability • Polypropylene or PVDF construction • Titanium, Hastelloy C or PVDF housing bolts • Custom mounting plates available • Accepts standard NEMA 56C or IEC 63, 71 and 80 with B14 frame motors • Maximum working pressure 80 psi (5.4 bar) • Maximum temperature: 140oF (60oC) • Maximum flow 60 gpm (13.6 m3/hr.), maximum head 100 ft. (20 m)
General Description
MSVKC Typical Applications: • High pressure/low flow chemical processing, spraying, bulk unload, and tank transfer applications • Plating recirculation/filtration, PCB etching and rinse • Water/waste water treatment, wet scrubber • Laboratory, pharmaceutical, photo processing

Popular Series

Series associated to this product and brand

Type

Title

Link

Data Sheets

MSVKC Vertical Multistage Pumps Datasheet (2022)

View

Installation & Operation Manuals

MSVKC Vertical Pumps Installation & Operation Manual (2022)

View

Features & Benefits

MSVKC Vertical Multi Stage Mag Drive Pumps Feature:
• Sealless mag drive technology - eliminates microbubbles
• Multi-Stage design: Generates increased head at low flow rates, low power consumption, wide hydraulic envelope allows for mix and match impeller sizes
• Unique interconnecting drive shaft - transmits torque from magnetic coupling to first stage impeller
• Independent thrust bearings at each stage for maximum reliability
• Polypropylene or PVDF construction
• Titanium, Hastelloy C or PVDF housing bolts
• Custom mounting plates available
• Accepts standard NEMA 56C or IEC 63, 71 and 80 with B14 frame motors
• Maximum working pressure 80 psi (5.4 bar)
• Maximum temperature: 140oF (60oC)
• Maximum flow 60 gpm (13.6 m3/hr.), maximum head 100 ft. (20 m)

General Description

MSVKC Typical Applications:
• High pressure/low flow chemical processing, spraying, bulk unload, and tank transfer applications
• Plating recirculation/filtration, PCB etching and rinse
• Water/waste water treatment, wet scrubber
• Laboratory, pharmaceutical, photo processing
