VKC8P48CVVN355C

Name: VKC8P48CVVN355C PumpCatalog Finish Thompson FTI
Brand: Finish Thompson FTI
SKU: VKC8P48CVVN355C
Price: 2177.76 USD
Availability: OutOfStock

Finish Thompson FTI Pump End VKC8P48CVVN355C Vertical Centrifugal, VKC Series Plastic Mag Drive, VKC8, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.50" Impeller, 60 psi, 67 GPM

Brand: Finish Thompson FTI

Series:

VKC Vertical Mag Drive Pumps

Item: VKC8P48CVVN355C

List: ~~$2,792.00~~

$2,177.76

Returns generally accepted within 30 days; manufacturer terms apply. View Returns Policy

Lead time and availability are subject to change.

Estimate Shipping

Zip Code

Overview

Finish Thompson FTI Pump End VKC8P48CVVN355C Vertical Centrifugal, VKC Series Plastic Mag Drive, VKC8, 1 1/2" Suction, 1" Discharge, FKM O-Ring, 3.50" Impeller, 60 psi, 67 GPM

Literature & Manuals

Find the manuals, product sheets and all the information you need

Type	Title	Link
Brochures	VKC Series Pumps Brochure (2022)	View
Data Sheets	KC, VKC, MSKC Series Pumps Performance Curves (2022)	View
Data Sheets	VKC Vertical Series Pumps Datasheet (2022)	View
Installation & Operation Manuals	VKC5.5 thru VKC10 Vertical Pumps Installation & Operation Manual (2022)	View

Series Information

VKC Vertical Mag Drive Pumps Information

Features & Benefits
VKC Vertical Mag Drive Pumps Feature: • Utilizes powerful neodymium magnets • Non-aerating (no micro-bubbles) • Reduced environmental emissions • No wetted shaft bearings • Mounts inside or outside of tank • Corrosion resistant Polypropylene or PVDF construction • Accepts standard NEMA or IEC motors • Modular build: in 6" increments from 12" (30 cm) to 60" (152 cm) • Up to 1.8 specific gravity • Maximum temperature 140oF (60oC) • Maximum working pressure: 60 psi
General Description
VKC Typical Applications: • High pressure/low flow chemical processing, spraying, bulk unload, and tank transfer applications • Plating recirculation/filtration, PCB etching and rinse • Water/waste water treatment, wet scrubber • Laboratory, pharmaceutical, photo processing

Popular Series

Series associated to this product and brand

Features & Benefits
VKC Vertical Mag Drive Pumps Feature: • Utilizes powerful neodymium magnets • Non-aerating (no micro-bubbles) • Reduced environmental emissions • No wetted shaft bearings • Mounts inside or outside of tank • Corrosion resistant Polypropylene or PVDF construction • Accepts standard NEMA or IEC motors • Modular build: in 6" increments from 12" (30 cm) to 60" (152 cm) • Up to 1.8 specific gravity • Maximum temperature 140oF (60oC) • Maximum working pressure: 60 psi
General Description
VKC Typical Applications: • High pressure/low flow chemical processing, spraying, bulk unload, and tank transfer applications • Plating recirculation/filtration, PCB etching and rinse • Water/waste water treatment, wet scrubber • Laboratory, pharmaceutical, photo processing
