Feature / Operational Area

HP Series Engineering Specifications

Pump Type

Double-Acting Piston (discharges on both forward and back strokes).

Flow Capacity

1 Quart per Full Cycle.

Lift & Head Limits

Max Suction Lift reaching up to 15 Feet vertical; Max Discharge Head up to 25 Feet.

Porting Dimensions

1" NPT standard inlet and outlet porting.

Housing Material Codes

Glass-Reinforced Polyester (Code P) or Ryton (Code R).

Elastomer & Gasket Setups

Viton (Code V): Viton gasket, Viton O-rings, Viton vacuum breaker .

Cork/Nitrile (Code N): Cork/Nitrile gasket, Viton O-rings, Viton vacuum breaker .

EPDM (Code E): EPDM gasket, EPDM O-rings, EPDM vacuum breaker.

Suction Tube Kit Options

Polyester Kit: 2-piece 1" Polyester, 34" long with Polyester coupling and Teflon tape .

Halar Kit: 2-piece 1" Halar, 34" long with Halar coupling and Teflon tape .

UHMW Polyethylene Kit: 2-piece 1" UHMW polyethylene, 34" long with Halar coupling and Teflon tape.

Discharge Hose Options

8' length with integrated Elbow & Nozzle available in:

• EPDM Hose (with Polyester or Fluoropolymer Elbow & Nozzle) .

• Nitrile Hose (with Polyester Elbow & Nozzle) .

• PVC Black Hose (with Polyester Elbow & Nozzle) .

• Clear Reinforced PVC Hose (with Polyester or Halar Elbow & Nozzle) .

• PVC Hose (with Fluoropolymer Elbow & Nozzle).

Discharge Spout Options

Polyester Discharge Spout or Fluoropolymer Discharge Spout.

Bung Adapter Compatibility

Polypropylene / Polyester Buttress Bung Adapter Assembly for HP Pumps.
