DPCMS4

Sta-Rite DPCMS4 DPC Series Medium Head, Self-Priming Centrifugal Pump. 1/2 HP, 115 Volts, 60 Hz, 3 Ph (Three Phase), TEFC - Totally Enclosed Fan Cooled Motor. Polycarbonate Impeller, 1-1/4" Suction, 1-1/4" Discharge, Manufactured by Pentair.

Brand: STA-RITE

Series:

DPC Medium Head Centrifugal Pump

Item: DPCMS4

Retail Price: $1,780.80

Ships within 1 business day (in-stock items). Delivery typically 1-5 business days.

Returns accepted within 30 days. View Returns Policy

Estimate Shipping

Zip Code

Overview

Literature & Manuals

Find the manuals, product sheets and all the information you need

Type	Title	Link
Brochures	DPC Centrifugal Pump Brochure	View
Installation & Operation Manuals	DPC Centrifugal Pump Manual	View

Series Information

DPC Medium Head Centrifugal Pump Information

Features & Benefits
Sta-Rite DPC Centrifugal Pump Features And Benefits: Built-In Thermal Overload Protection with Automatic Reset Mechaucal Shaft Seal with Buna-N Elastomers, Carbon and Ceramic Sealing Surfaces, and Stainless Steel Parts Shielded, Permanently Lubricated Bearings Ensure Extended Life and Smooth, Quiet Operation Built-In Check Valve
General Description
Sta-Rite DPC Centrifugal Pump General Specifications: BODY CONSTRUCTION: Cast Iron HORSEPOWER: 1/2 HP MAXIMUM CAPACITY: 43 GPM FLOW at 10' LIFT and 20 PSI: 25 GPM MAX LIFT: 25' MAXIMUM DISCHARGE PRESSURE: 26 PSI MAXIMUM TOTAL PRESSURE (Inlet + Pump Pressure): 60 PSI SUCTION SIZE: 1-1/4" NPT DISCHARGE SIZE: 1-1/4" NPT VOLTAGE: 115v, 60 Hz MAXIMUM LIQUID TEMPERATURE: 130°F (55°C)

Related Products and Parts

Popular Series

Series associated to this product and brand

DPCMS4

Type

Title

Link

DPC Centrifugal Pump Brochure

View

DPC Centrifugal Pump Manual

View

Features & Benefits

Sta-Rite DPC Centrifugal Pump Features And Benefits:
Built-In Thermal Overload Protection with Automatic Reset
Mechaucal Shaft Seal with Buna-N Elastomers, Carbon and Ceramic Sealing Surfaces, and Stainless Steel Parts
Shielded, Permanently Lubricated Bearings Ensure Extended Life and Smooth, Quiet Operation
Built-In Check Valve

General Description

Sta-Rite DPC Centrifugal Pump General Specifications:
BODY CONSTRUCTION: Cast Iron
HORSEPOWER: 1/2 HP
MAXIMUM CAPACITY: 43 GPM
FLOW at 10' LIFT and 20 PSI: 25 GPM
MAX LIFT: 25'
MAXIMUM DISCHARGE PRESSURE: 26 PSI
MAXIMUM TOTAL PRESSURE (Inlet + Pump Pressure): 60 PSI
SUCTION SIZE: 1-1/4" NPT
DISCHARGE SIZE: 1-1/4" NPT
VOLTAGE: 115v, 60 Hz
MAXIMUM LIQUID TEMPERATURE: 130°F (55°C)
