Goulds Water Technology Pumps Models NPE (close-coupled) and NPE-F (frame mounted) are end suction, single stage centrifugal pumps for general liquid transfer service, booster applications, etc. Liquid-end construction is all AISI Type 316 stainless steel, stamped and welded. Impellers are fully enclosed, non-trimable to intermediate diameters. Casings are fitted with a diffuser for efficiency and for negligible radial shaft loading. Close-coupled units have NEMA 48J or 56J motors with C-face mounting and threaded shaft extension. Framemounted units can be coupled to motors through a spacer coupling, or belt driven.

The Series NPO embraces a line of 1", 1¼" and 1½" NPT discharge, general liquid transfer and booster pump application end suction centrifugal pumps. The liquid end construction is of AISI 316 stainless steel, stamped and welded. Open vane impellers are ideal for liquids with suspended solids to 3⁄8" diameter.

The NPO (or open impeller NPE) was developed as a result of Goulds Water Technology experience with the commercial dishwasher market. In addition, it builds on the strength of our NPE market presence and allows us to enter other high volume markets where small solids or particulate handling is required. The exclusive Goulds Water Technology fabricated stainless design also offers considerable advantages over our major competitors in these markets.

The NPO pump from Goulds Water Technology is an open impeller, single stage, end suction centrifugal made of 316 stainless steel for a variety of commercial washing applications. It consists of three pump sizes using 1⁄2-71⁄2 HP motors in a variety of enclosures. Many of the options for the NPE including seals and the vent/flush accessory are also available for the NPO. The casing is a modification of the NPE casing which incorporates a flat running surface for the front of the open impeller. The impeller for the smalles size is a cast 316 open design similar to that used in the ICS. Impellers for the two larger sizes are fabricated 316L. The seal housing and seal are identical to those used on the NPE.

Goulds Water Technology Pumps e-SV Series Stainless Steel Vertical Multi-Stage Pump. The e-SV pump is a non-self priming vertical multistage pump coupled to a standard motor. The liquid end, located between the upper cover and the pump casing, is held in place by tie rods. The pump casing is available with different configurations and connection types. Why “e”-SV? “e” stands for the ultimate in energy efficiency, easy installation and economical operation - a new generation of vertical, multi-stage pumps that deliver outstanding performance and reliability. Developed based on intensive research into user needs, the new e-SV pumps are designed to extend uptime and help reduce lifecycle costs in a wide variety of demanding applications such as Water Supply and Pressure Boosting, Water treatment, Light Industry, Irrigation and Farming, Heating, Ventlation and Air Conditioning (HVAC).

Goulds Water Technology e-SV repair stacks for e-SV Series Stainless Steel Vertical Multi-Stage Pumps (All Speeds).

e-SV: How to Repair the Stack Assembly and Change a Seal

Goulds Water Technology e-AB2 variable speed pump controller and complete booster package kits, provide an economical answer for municipal water district customers with low water pressure. Both domestic and light commercial applications can benefit. As water use increases, the controller changes pump speed to maintain pressure. Large supply tanks are eliminated and less wear and tear on your pump and motor. Think of it as “Cruise Control” for your pump! The e-AB2 is available with a range of flow rates to handle homes with up to four baths, irrigation, filtration and fire suppression systems. Light commercial applications up to 100 GPM at 55 PSI boost. The e-AB2 is available as either a separate controller or as part of a complete pump package with everything you need to plumb it to a domestic water line.

Goulds Water Technology Aquavar Intelligent Pump Controller from CentriPro utilizes an all new Aquavar platform, and combines it with over 20 years of variable speed pumping experience. The Aquavar is designed to provide variable frequency pumping control of speed, pressure, flow and level over a wide range of submersible and above ground applications.

Goulds Water Technology Pumps Repair & Replacement Pump Parts for all Models

Availabe Repair Part Types include:

Adapter, Assembly, Cord, Handle, Diffuser, Bearing, O-Ring / Ring,, Seal, Base, Spacer, Bearing, Washer, Bolt, Bowl, Bracket, Bushing, Cable, Cap, Capacitor, Case, Casing, Clamp, Coupling, Cover, Cutter, Deflector, Slinger, Diaphragm, Diffuser, Bearing, Disconnect, Elbow, Fitting, Flange, Foot, Gasket, Gland, Guard, Guidevane, Housing, Impeller, Key, Motor, Nut, Stud, Plug, Overload, Packing, Pin, Plate, Retainer, Retaining Ring, Screw,Shackle, Shaft, Coupling, Sleeve, Spring, Strainer, Stud, Tie Rod, Tubing / Tube, Valve, Wear Ring.

Goulds Water Technology e-SH Pumps, New Product Offering - 316 SS End Suction Close Coupled & Frame Mounted Models

Ultimate performance with expected realiability from a Xylem product. The end suction e-SH stainless steel pumps (316 SS), centrifugals feature a corrosion resitent impeller that is also stainless steel. These are replacements to the previous SSH models so the casings and dimensions may look familair. The boost comes from an overall improvement on efficiency and total performance.

e-SH-C / e-SH-F Closed Coupled and Frame Mounted S-Group & M-Group Models

Suitable for pairing with the Aquavar IPC or the Hydrovar Variable Speed Controller. You can expect to see energy saving upwards of 70% versus a fixed speed configuration.

Specifically designed to move water, non aggresive or moderate liquids in commercial building applications. On the industrial side this pump is ideal for an array of OEM pumping applications such as water intake, water transfer, circulation, pressure boosting, heating and cooling processes, transport and fluid transferwater boosting and boiler feed booster.

Perfect for pumping liquids such as:

• Produced Water
• Potable Water
• Process Water
• Heat Transfer Fluids
• Gray & Used Water
• Groundwater

Industries

• Oil & Gas
• Commercial Buildings
• General Manufacturing
• Power Generation

e-SHX Smart Pump

Integrated pump, motor & variable speed drive solutions powered by Hydrovar® X

The brand new and improved Goulds Water Technology e-SHX Pump Series! High performance stainless steel centrifugal end-suction pump. The e-SHX is fully made in AISI 316 stainless steel which makes it suitable for handling water as well as non-aggressive or moderately aggressive fluids. The pumps are equipped with interchangeable mechanical seals, hydrovar® X Motor in three phase, and have a back pull-out design (impeller, bracket and motor can be extracted without disconnecting the pump body from the piping). Pumps assembled at the factory are certified to the NSF/ANSI 61 Drinking Water System Components Standard.

APPLICATIONS

The e-SHX is suitable for a wide range of non-aggressive to mildly aggressive fluids in commercial building, industrial & diverse OEM applications.

• Water intake
• Water transfer and circulation
• Pressure boosting
• Process cooling and heating
• Fluid transfer and transport
• Produced water transfer and boosting
• Boiler feed booster

Unleash the power of hydrovar X! Powered by Xylem’s hydrovar® X Smart Motor, e-SHX Smart Pumps offer customizable pumping solutions designed to deliver ultra-premium efficiency, connectivity, and simplicity right out of the box. e-SHX Smart Pumps integrate decades of expertise and know-how in pumping solutions to bring the right combination of motors, variable speed drive and hydraulic pumps in one comprehensive, highly efficient package. e-SHX Smart Pumps feature AISI 316 stainless steel construction for reduced corrosion and improved strength and ductility. Each pump comes equipped with interchangeable mechanical seals. The back pull-out design simplifies maintenance by allowing the impeller, bracket and motor to be extracted without disconnecting the pump body from the piping. Suction and discharge flanges mate easily with ANSI class 150 flanges. The e-SHX can handle liquid temperatures up to 250° F. When it’s time to think efficiency, performance and reliable market-leading technology … start with e-SHX Smart Pumps from Goulds Water Technology – a complete system, delivering the solutions you need for today.

E-SVI Immersible Multistage Pumps Taking reliability and performance to new depths

The e-SVI is an efficient, reliable, high-performance pumping package, comprised of an energy saving, vertical multistage pump coupled to a NEMA premium-efficient motor. Plus, an immersible hydraulic end provides an ideal solution for top mount applications. With flows up to 150 GPM and sizes from 1 to 22, the e-SVI meets the demands of a wide variety of applications in the industrial, OEM and commercial building services markets.The e-SVI can be built with a variable number of stages to cover a wide range of duty points. It’s configured to allow an additional number of blank stages, so that the height of the immersed part can accommodate different suction depths. It can serve as an interchangeable drop-in replacement for pumps with .75", 1.25" or 2" NPT threaded fittings. Built in Auburn, NY, the e-SVI is a powerful complement to the existing e-SV multistage pump family. In addition, the e-SVI can be paired with the Hydrovar® drive or the ultra-premium efficient Smart Motor to provide variable speed performance.

e-HMX Smart Pump

Integrated pump, motor & variable speed drive solutions powered by Hydrovar® X

e-HMX Smart Pumps feature the right combination of ultra-premium efficient motors with integrated variable speed drives and pumps to ensure great performance and a rapid return on investment in nearly any application. The result is intelligence, performance, connectivity, and simplicity in one comprehensive package, from one reliable source - Goulds Water Technology.

Ultra-premium package bringing market-leading performance right out of the box!

Powered by Xylem’s hydrovar® X Smart Motor, e-HMX Smart Pumps offer customizable pumping solutions designed to deliver ultra-premium efficiency, connectivity, and simplicity right out of the box! e-HMX Smart Pumps integrate decades of expertise and know-how in pumping solutions to bring the right combination of motors, variable speed drive and hydraulic pumps in one comprehensive, highly efficient package. It is a versatile horizontal multistage pump designed for best-in-class efficiency and superior durability to reduce the total cost of ownership. Customizable options mean you get exactly the right pump for your application, exactly when you need it. So, when it’s time to think efficiency, performance and reliable market-leading technology. Start with e-HMX Smart Pumps from Goulds Water Technology – a complete system, delivering the solutions you need for today.

Simple: Built-in application software makes the hydrovar X one of the easiest drives to commission, program and operate, enabling virtually any configuration of pumps.

Sustainable: No rare earth materials are used to minimize product availability challenges and address environmental concerns while offering smart technology and superior performance.

Intelligent performance: Advanced system controls (up to 8 pumps) are customizable for a wide range of applications. The IE5 “ultra- premium” hydrovar X smart motor provides one of the broadest efficiency ranges in the industry.

Ease of installation & maintenance: Integrated pump and hydrovar X motor design eliminates the need for additional wiring, labor and associated costs.

Built-in protections: Integrated functions provide protection for the pump and motor while optimizing performance.

Easy service: VFD and/or motor can be easily replaced individually, minimizing downtime and expensive repair.

Compact motor design: hydrovar X motors offer higher performance with a reduced footprint when compared to Aquavar IPC solutions. Increased performance reduces electricity consumption and lowers life cycle costs.

e-HMX Smart Pump Specifications

• Flow rate: up to 150 GPM (34 m³/h)
• Head: up to 509 ft (155 m)
• Temperature of pumped liquid: 20ºF to 248ºF (-30ºC to 120ºC)
• Maximum operating pressure: 230 psi (16 bar)
• Environment temperature: -4ºF to 122ºF (-20ºC to 50ºC)

e-SVX Smart Pump

Integrated pump, motor & variable speed drive solutions powered by Hydrovar® X

Xylem’s hydrovar® X line of products combine ultra-premium efficient motors with integrated variable speed drives and pumps. The result is intelligence, performance, connectivity, and simplicity in one comprehensive package, from one reliable source - Goulds Water Technology.

Ultra-premium package bringing market-leading performance right out of the box! Powered by Xylem’s hydrovar® X Smart Motor, e-SVX Smart Pumps offer customizable pumping solutions designed to deliver ultra-premium efficiency, connectivity, and simplicity right out of the box!

e-SVX Smart Pumps integrate decades of expertise and knowhow in pump technology to bring the right combination of motors, variable speed drive and hydraulic pumps in one comprehensive, highly efficient package. The e-SVX is built to withstand a variety of mechanically aggressive and high temperature liquids such as glycol, oils/solvents, and more. It features 10 different sizes and each can be specially configured for a wide range of environments. It’s an ideal solution for residential, light commercial, industrial, agricultural, and OEM water supply as well as HVAC applications. So, when it’s time to think efficiency, performance and reliable market-leading technology … start with e-SVX Smart Pumps from Goulds Water Technology – a complete system, delivering the solutions you need for today.

Standard features of e-SVX Smart Pumps

The e-SV pump, the product at the heart of the e-SVX Smart Pump Series, is one of the highest efficiency multistage pumps on the market today. This fabricated vertical multistage pump is also easy to install and economical to maintain. When it comes to efficiency, all of the pumps in the e-SV product family deliver!

Simple: Built-in application software makes the drive one of the easiest to commission, program and operate, enabling virtually any configuration of pumps.

Sustainable: hydrovar X is a smarter green technology solution. No rare earth materials are used to minimize product availability challenges and address environmental concerns while offering smart technology and superior performance with a “green heart”.

Intelligent performance: Advanced system controls (up to 8 pumps) are customizable for a wide range of applications. The IE5 “ultra-premium” hydrovar X smart motor provides one of the broadest efficiency ranges in the industry.

Ease of installation & maintenance: Integrated pump and hydrovar X motor design eliminates the need for additional wiring, labor and associated costs.

Built-in protections: Integrated functions provide protection for the pump and motor while optimizing performance.

Easy service: VFD and/or motor can be easily replaced individually, minimizing downtime and expensive repair.

Compact design: hydrovar X motors offer higher performance with a reduced footprint when compared to the legacy Packaged Hydrovar solution. Increased performance reduces electricity consumption and lowers life cycle costs.

e-SVX Smart Pump Specifications

• Flow rate: up to 640 GPM (145 m3/h)
• Head: up to 1200 ft (366 m)
• Temperature of pumped liquid: -20ºF to 250ºF (-30ºC to 121ºC)
• Maximum operating pressure: 580 psi (40 bar)
• Environment temperature: -4ºF to 122ºF (-20ºC to 50ºC

Goulds Water Technology GFE Cast Iron Effluent Pumps

The GFE Series of submersible effluent pumps are designed for Homes, Hospitals, Motels, Schools, Farms & Trailer Courts / Mobile Home Parks.

• Cast iron motor housing allowing for optimal heat dissipation.
• Premium mechanical seal design provides superior protection against sand and abrasive damage (Silicon Carbide/Silicon Carbide/BUNA).
• Engineered motor designed for peak hydraulic performance without overloading.
• Durable cast iron base for stability.
• Cast iron impeller with dual vanes. Balanced for smooth operation. (3/4 HP, high head is glass reinforced thermoplastic.).
• Corrosion resistant hardware for lifetime use.
• Capable of running dry without damage to components.
• Designed for continuous operation when fully submerged.
• All models have NEMA three prong grounding plugs.
• Available in automatic and manual models.

Goulds Water Technology GFK GFV Submersible Sewage Pumps

The GFK & GFV Series is a range of submersible sewage pumps that are proven to deliver dependable performance.

Based on technology developed and tested in tough environments throughout the world, count on the GFK & GFV Series available through Goulds Water Technology to ensure reliability and reduce downtime in harsh residential, light commercial and industrial wastewater applications.

The Industry Standard for High-Volume Irrigation and Water Transfer

The Goulds GT IRRI-GATOR is a high-performance self-priming centrifugal pump engineered for residential and small commercial water systems. Built for relentless dependability, the GT series is the preferred choice for applications requiring consistent water flow from shallow wells, lakes, or storage tanks. Whether you are managing a large-scale lawn sprinkling system or agricultural water transfer, these pumps deliver the pressure and volume needed to keep your systems running at peak efficiency.

Engineered for Performance and Longevity

The GT series is built to withstand the elements and provide years of continuous operation. Key design features include:

• Self-Priming Design: Once the pump is manually filled for the first time, it is capable of repriming automatically whenever the water level rises above the suction pipe—handling suction lifts up to 25 feet.

• Rugged Cast Iron Construction: The heavy-duty casing is treated with an electro-coat paint process, baked on both inside and out for superior corrosion and abrasion resistance.

• Continuous Operation Rating: Powered by a NEMA standard motor, these pumps are designed to operate 24/7 within their recommended limits without risk of motor damage.

Technical Performance Summary

Built-In Serviceability

Longevity is at the heart of the IRRI-GATOR design. The Back Pull-Out Design allows for the entire pump to be disassembled for maintenance or repair without ever disturbing the existing piping. The two-compartment motor also provides simplified access to wiring and replaceable components, significantly reducing labor time and maintenance costs.

Versatile Application Range

The Goulds GT IRRI-GATOR is the definitive choice for:

• Residential Irrigation: High-volume lawn and garden sprinkling.

• Water Transfer: Moving water from ponds, lakes, or storage tanks.

• Agricultural Support: Small-scale farm irrigation and dewatering.

• Climate Control: Reliable circulation for heat pumps and air conditioning systems.

Goulds Water Technology Aquavar Intelligent Pump Controller (IPC) Repair Parts - LCP Mounting Kits, Option Cards, Enclosure Kits, Control Boards and Accessory Bags.

CentriPro DV/DT Output Filters - dv/dt filter recommended for applications with motor leads longer than 50. It is recommended to use the dv/dt filter with all submersible applications

Goulds Water Technology Pumps Aqua Boost II Controller/Booster System - The AquaBoost II variable speed pump controller and complete booster package kits, provide an economical answer for municipal water district customers with low water pressure. Both domestic and light commercial applications can benefit. As water use increases, the AquaBoost II changes pump speed to maintain pressure. Large supply tanks are eliminated and less wear and tear on your pump and motor.

Goulds Water Technology The Aquavar CPC is offered in a wall or floor mounted design up to 550 HP, 460 volt, single phase input up to 50 HP, 208 230 volt and three phase 208-230 volt up to 100 HP.

The latest software provides more versatility and flexibility with centrifugal pump applications than ever before! With all the available Aquavar Products, Goulds Water Technology provides the pump professional with more options for a complete variable speed pumping system.

Goulds Water Technology AquaStart is a combination soft starter that allows easy installation with factory pre-set pump parameters. It is designed to work directly with centrifugal and submersible pumps with ease of installation. AquaStart utilizes Thermal Image Motor Protection (TIMP) to get the highest level of motor performance while fully protecting the motor for longer life. AquaStart offers enhanced motor and system protection for residential, commercial, and industrial pumping applications.

Goulds Water Technology Pumps Hydrovar controller is a combination of a variable frequency drive and a programmable logic controller (PLC) in one compact package, which can be mounted on the fan cover of a TEFC pump motor. Drives are pre-programmed with patented pump specific software, designed for centrifugal pumps. They match pump output to a wide range of system conditions while protecting the pump, the motor and the pumping system.

Hydrovar drives provide superior system pressure control over a wide range of flow rates. As demand changes the drive adjusts the speed of the motor to compensate, keeping output pressure nearly constant. And Hydrovar drives reduce energy usage and cost. By slowing the speed of the pump, the Hydrovar eliminates the inefficiencies of full speed systems. With lower energy and maintenance costs they can pay for themselves in under 2 years!

Goulds Water Technology Pumps SSH-S M Group Pumps offer a Frame Mounted Version, SSH-F and a Close Coupled Model SSH-C which are specifically designed for all traditional cast iron or bronze fitted water and low grade corrosive servies. Applications include: Water Circulation, Booster Systems, Liquid Transfers, HVAC Pump Replacements and General Service Pumping.

Goulds Water Technology Pumps 3642 (closed-coupled) and 3742 (frame-mounted) are single stage, end suction, centrifugal pumps for water circulation, booster service, liquid transfer, spraying systems, jockey pump and general service pumping. Pumps are available in three different materials of construction: all iron, bronze-fitted and all bronze.

Pump impellers are enclosed design for high efficiency, threaded directly on the motor shaft. Close-coupled units have NEMA standard frame motors with C-face mounting and threaded shaft extensions. Frame mounted units can be coupled to motors through a spacer coupling, or belt driven.

Goulds Water Technology Centrifugal Pumps 3656 LH / 3756 LH are Low Head, Cast Iron, Bronze Fitted, End Suction desined for Evaporative Condensors, Industrial Fluid Coolers, Refrigeration and Air Conditioning Systems, Water Circulation, Liquid Tranfer and Irrigation Applications.

The 3656 and 3756 M & L-Group pumps from Goulds Water Technology have been designed with technical benefits to meet the needs of users in a variety of water supply, recirculation, and cooling applications with Flanged connections.

The 3656 and 3756 S Group pumps from Goulds Water Technology have been designed with technical benefits to meet the needs of users in a variety of water supply, recirculation, and cooling applications. These pumps are available in Cast Iron, Bronze Fitted or All Iron configurations as well as Close Coupled, 3656 model and Frame Mount 3756 model.

Goulds Water Technology Models 3657 (close-coupled) and 3757 (frame-mounted) are single-stage end-suction pumps designed for ultra-pure water systems, O.E.M. applications, food and beverage processing and chemical services not demanding ANSI standard equipment.

The pumps have fully enclosed, investment cast, AISI TYPE 316 stainless steel impellers, key driven and held in position by an o-ring sealed locknut. The full volute casings are also investment castings of AISI TYPE 316 stainless steel, back pull-out configuration, with connections for mating with standard 150 lb. ANSI flanges. Shafts are protected with o-ring sealed stainless steel sleeves. Shaft sealing is with mechanical seal.

Goulds Water Technology e-HM series of horizontal multi-stage pumps designed expressly for commercial and industrial use. The e-HM uses the market-proven hydraulics of the e-SV, which helps the e-HM offer market leading efficiency. The high-efficiency motor means that you can use less pump for more performance. The standard balanced impeller reduces axial thrust 40%, therefore; extending motor bearing life. The e-HM also boasts a 20% increase in body thickness enhancing durability, and further reducing lifecycle costs.

The Model HMS is a close coupled, end suction, multi-stage centrifugal pump for general liquid transfer service, booster applications, etc. Liquid-end construction is all AISI Type 316 stainless steel, stamped and welded. Impellers are fully enclosed, non-trimmable to intermediate diameters. Casings are fitted with diffusers for efficiency and for negligible radial shaft loading. All units have NEMA 48Y or 56Y motors with square flange mounting and threaded shaft extension.

All Goulds Water Technology HMS Pumps Are Obsolete With No Replacement

Goulds Water Technology Model LB is a single stage, centrifugal jet pump for general liquid transfer service and booster applications. The liquid end utilizes a 304SS stamped casing, Noryl® impeller, Lexan® ejector and guidevane, Amodel® motor adapter and EPR o-rings. All motors are NEMA 48Y and 56Y square flange with a 304SS threaded shaft extension.

Goulds Water Technology Model LC is a close-coupled, end suction, two stage centrifugal for general liquid transfer service, booster applications, etc. Liquid-end construction is all AISI Type 304 stainless steel, stamped and welded. Impellers are fully enclosed, non-trimable to intermediate diameters. Casings are fitted with diffusers for efficiency and for negligible radial shaft loading. All units have NEMA 48Y and 56Y motors with square flange mounting and threaded shaft extension.

Goulds Water Technology Model MCS is a close coupled, end suction, centrifugal pump for general liquid transfer service, booster applications, etc. Liquid-end construction is all AISI Type 304 stainless steel, stamped and welded. Impellers are fully enclosed, non-trimmable to intermediate diameters. Casings are fitted with diffusers for efficiency and for negligible radial shaft loading. All units have NEMA 48Y or 56Y motors with square flange mounting and threaded shaft extension.

Goulds Water Technology Models ICS, close coupled, and ICS-F, frame mounted, are single stage, end suction pumps designed for ultra pure water systems, beverage processing, chemical service and selected OEM applications. The pumps are of back pullout configuration, with NPT suction and discharge connections and have investment cast AISI Type 316 stainless steel casings, open impellers and seal housing. All pumps are equipped with O-ring shaft sleeve protection and are available with a variety of optional mechanical seals. Close coupled units are equipped with C-face NEMA motors with threaded shaft extensions. Frame mounted units can be baseplate mounted and are available with spacer couplings or may be belt driven. Close coupled units are available with single and three phase ODP, TEFC and explosion proof motors. Consult with your distributor/dealer for additional information.

Goulds Water Technology Pumps model HSC is a multi-stage, end-suction, centrifugal pump for general liquid transfer service, booster applications, etc. Liquid-end construction is cast iron, stainless steel and engineered composites. All units have NEMA 48 Frame single-phase, 115/230 V, 60 Hz motors with C-face mounting and NEMA 56J threaded shaft extensions.

Goulds Water Technology Pumps Primeline SP SPM/SPH Series embraces a line of end suction single stage, self-priming centrifugal pumps for lawn sprinkling, HVAC systems, and general water transfer. Casing is cast iron construction with tapped openings provided for vacuum gauge and casing drain. Impeller is bronze, enclosed design, balanced for smooth operation and keyed to motor shaft. ALL motors are NEMA standard, 3500 RPM, open drip proof or TEFC enclosure.

Goulds Water Technology Model MCC is a close coupled, end suction, centrifugal pump for general liquid transfer service, booster applications, etc. Liquid-end construction is cast iron and AISI Type 316 stainless steel. Impellers are fully enclosed, non-trimmable to intermediate diameters. All units have NEMA 48Y or 56Y motors with square flange mounting and threaded shaft extension.

Goulds Water Technology Models 45HB and 70HB are multi-stage, high-pressure, general-purpose centrifugal booster pumps, using enclosed impellers. Applicable for clear, non-hazardous liquids in general industrial services up to 180°F (82°C). Particularly suited for high-pressure booster services. All models are close-coupled to electric motors containing prelubricated bearings designed for continuous service. Threaded shaft extension is protected by a stainless steel sleeve/coupling combination. All models are equipped with single, unbalanced mechanical shaft seals. Units are shipped completely assembled and ready for installation.

Goulds Water Technology GB Series pump is a portable horizontal multi-stage pump designed for residential and agricultural washdown, misting and general boosting services. The 304 stainless steel version of the GB is used for HVAC, general commercial, reverse osmosis and filtration applications.

Goulds Water Technology NPV and SHV Series pumps are vertically immersed, end-suction designed pumps for general liquid transfer service, machine tool coolant, parts washer, filtration, waste treatment and OEM applications. Liquid-end construction is all AISI 300 series stainless steel. These pumps are not designed for applications requiring ANSI, FDA or NSF ratings and are not recommended for use in highly abrasive services such as grinding. Impellers are available in enclosed and open configurations depending on the model. Enclosed impeller versions of the NPV are fitted with a diffuser for high efficiency and for negligible radial shaft loading. NPV units have NEMA 56J motors with C-face mounting and threaded shaft extensions. SHV units have NEMA standard JM frame motors.

Goulds Water Technology Pumps 1SC Series Bottom Suction, Drainage Submersible Booster Pump is designed for pumping water out of reservoirs and storage tanks for delivery to the homes, farms, mobile home parks, motels, schools and hospitals as wella s servicing a number of municipal, industrial and commercial applications.

Goulds Water Technology SE Pumps - Potable Water Boosters and Filtered Effluent Service, Multi-Stage, Bottom-Inlet and High Head Submersibles. Residential Water Systems and Wastewater that are ideal for filtered onsite effluent systems, Cistern booster systems, Shallow dug wells, Shore wells, and Aeration applications.

Goulds Water Technology Pumps 1DW Series are specifically designed for the following uses: Handling dirty waters, Draining ditches and pits, Excavating in the building trades, Water transfer and Industrial water drainage or transfer.

Goulds Water Technology Pumps 1DM & 2 DM are Non-clog submersible sewage pumps for simplex and duplex installations in small lift stations, drainage systems or raw water applications requiring solids handling capability of 13⁄8" and 2" diameter made specifically for: Homes and farms, Mobile home parks and motels, Schools and hospitals, Municipal package systems, Industrial treatment systems and Dewatering applications

Goulds Water Technology Pumps 1DV & 2DV 1 1/2" and 2" Submersible Vortex Sewage Pump for simplex and duplex installations in small lift stations, drainage systems or raw water applications requiring solids
handling capability of 13⁄8" and 2" diameter. the 1DV/2DV series is specifically designed for industrial treatment systems, mobile home parks and motels, municipal package systems as well as schools and hospitals.

Goulds Water Technology STS sump pumps are energy-efficient residential sump pumps available in two models the STS21, and the STS31. The 1/4hp and 1/3hp pumps are stainless steel and feature less amp draw for greater energy efficiency. These wastewater / Drainage pumps are specifically designed for the following applications, basement draining, dewatering, water transfer and filtered effluent.

Goulds Water Technology Pumps 3885 WE Series Submersible Effluent Pumps are Specifically designed for the following uses: Homes, Farms, Trailer Courts, Motels, Schools, Hospitals, Industry and Effluent Systems.

Goulds Water Technology Pumps 3886 WS B Series Residential Wastewater Sewage Pump is designed for applications in the Home, Sewage Systems, Dewatering Effluent and Water Transfer.

Goulds Water Technology Pumps 3887 WS BF Series Residential Wastewater Sewage Pump is specifically designed for multiple applications such as Homes, Sewage Systems, Dewatering / Effluent, Water Transfer, Light Industrial and Commercial uses. Anywhere waste or drainage must be disposed of quickly, quietly and efficiently you can count on the WS BF 3887 Goulds Water Technology Pump.

Goulds Water Technology Pumps 3887 WS BHF Series Residenatial Wastewater Sewage Pump is specifically designed for multiple applications such as Homes, Sewage Systems, Dewatering / Effluent, Water Transfer, Light Industrial and Commercial uses. Anywhere waste or drainage must be disposed of quickly, quietly and efficiently you can count on the WS BHF 3887 Goulds Water Technology Pump.

Goulds Water Technology Pumps 3888 D3 WS Series Sewage Pump is designed for residential wastewater applications including Sewage Systems, Flood & Pollution Control, Dewatering Effluent, Farms, Hospitals Trailer Courts and Motels.

Goulds Water Technology Pumps 3888 D4 WS Series Sewage Pump is designed for residential wastewater applications including Sewage Systems, Flood & Pollution Control, Dewatering Effluent, Farms, Hospitals Trailer Courts and Motels.

Goulds Water Technology Pumps 1GD Dual Seal Submersible Grinder Pump is designed for High Head Sewage applications where a gravity system is not proctical. The 1GD Series is ideal for pressure Sewage Sytems.

Goulds Water Technology Pumps 2WD / 3WD Submersible 2" & 3" Sewage Pump are designed for Sewage Systems, Dewatering and Effluent Applications, Water Transfer, Industrial & Commercial Proccesses.

Goulds Water Technology Pumps PE Models are specifically designed for the following applications: On-Site Wastewater Treatement- Mound Systems, Effluent/Dosing Systems, Low Pressure Pipe Systems, Basement Draining and Heavy Duty Sump/Dewatering.

Goulds Water Technology Pumps PS Submersible Sewage Pump is designed for residential wastewater pumping applications such as sewage systems, heavy duty sump and dewatering as well as water transfer.

Goulds Water Technology Pumps PV Series are specifically designed for use with the following applications: Residential Sewage Systems, Heavy Duty Sump / Dewatering and Water Transfer.

Goulds Water Technology Pumps RGS Residential Grinder Pump Series is designed for high head sewage applications where gravity systems are not practical or ideal for pressure sewage systems.

Goulds Water Technology Pumps 2ED Submersible Effluent Pump is designed for many purposes including Farms, Hotels / Motels, Hospitals, Trailer Parks / Courts, Schools, Industry and Effluent Systems.

Goulds Water Technology Pumps 3SD Submersible Sewage Pump is designed for use in many applications such as Residential, Commercial and Industrial, Sewage Systems, Hospitals, Flood & Pollution Control, Dewatering & Effluent, Trailer Courts, Motels and Farms.

Goulds Water Technology Pumps 4SD Submersible Wastewater Sewage Pump is designed for use with Sewage Systems, Flood and Pollutions Control, Effluent and Dewatering Systems, Farms, Hospitals, Trailer Courts and Motels.

Goulds Water Technology Pumps 4SDX Explosion Proof 4" Sewage Pumps are designed for an array of hazerdous commerical and industrial applications such as Sewage Systems, Flood and Pollutions Control, Dewatering and Effleunt, Hospitals, Trailer Courts, Hotels and Motels.

Goulds Water Technology Pumps 3SDX 3" Explosion Proof Submerisble Sewage Pump is desinged for commercial hazerdous applications such as, Sewage Systems, Flood & Pollution Control, Dewatering and Effleunt, Hospitals, Trailer Parks as well as Hotels and Motels.

Goulds Water Technology Pumps 4NS 4" Non-Clog Submersible Sewage Pump is designed for applications such as, Sewage Systems, Flood & Pollution Control, Industrial Dewatering, Wastewater Treatment Plants and Municipal & Subdivision Lift Stations.

Goulds Water Technology Pumps 4XD 4" Non Clog Explosion Proof Sewage Pumps are designed for commercial applications such as, Sewage Systems, Flood & Pollution Control, Industrial Dewatering, Wastewater Treatment Plants and Municipal and Subdivision Lift Stations.

Goulds Water Technology Pumps line of GV Plus submersible vortex sewage pump is designed for maximum durability and reliability for building services applications. They feature a vortex style dynamically balanced impeller, dual mechanical seal and float leakage sensor. The pumps are designed for continuous operation when fully submerged and are capable of running dry without damage to components.

Goulds Water Technology Pumps 1GA / 2GA / 1GA(X) / 2G(X) Wastewater 1 1/2" and 2" Submersible Grinder Pump is designed for High Head & Pressure Sewage Systems for Municipal, Commercial and Industrial Applications.

Goulds Water Technology Pump 3872 WW Series Sewage Pumps are Specifically designed for the following uses: Residential sewage systems, Dewatering & Water transfer. Anywhere waste or drainage must be disposed of quickly, quietly and efficiently.

Goulds Water Technology ST31 "Sump Thing" Sump Pumps are designed for water transfer, basement draining, dewatering and effluent transfer. These pumps are corrosion resistant, cast iron body and feature a replaceable power cord.

Goulds Water Technology Pumps EP04, EP05 3871 Series are specifically desingned for use with effluent systems, Homes and Farms, Heavy Duty Sump Pump Application, Water Transfer and Dewatering.

Goulds Water Technology Pumps LSP03 & LSP07 Effluent Submersible Sump Pump is specifically designed for basement draining, water transfer and dewatering.

Goulds Water Technology Pumps LEP07 Submersible Effluent Pump is designed for residential wastewater applications. Specifically for wastewater treatment on-site with heavy duty sump, water transfer, effluent systems and dewatering.

Goulds Water Technology Pumps 2DW Ditch Wizard Series Dewatering pumps are intended to be used for pumping water which may contain abrasive particles. The pumped liquid may contain particles up to a size which corresponds to the openings in the strainer. Specifically designed to remove water from Drainage ditches, Trenches, Basements, Manholes and Excavating drainage in the building trades.

Goulds Water Technology GWP Plumber Wastewater Package Systems with PS and PV Pumps Pump/Basin Packages come fully assembled from the factory for simplified installation. The structural foam cover is strong and corrosion resistant. Vent grommets for both 2" and 3" vent provided. Adds system flexibility and reduces inventory. Applications include homes, rural water districts, parks, dewatering, wastewater, 2" solids handling, sewage lift stations, waste drainage below sewer line.

Goulds Water Technology SDS-ST / SDS1 Wastewater Sink Drain System were specifically designed for use in Laundry trays, Wet bar Sinks, Residential dishwashers, Beautician sinks and Air conditioning / dehumidifier condensate applications. Fully Assembled – Individually Cartoned. Capable of Running Dry without Damage to Components. Severe Duty Rated Oil and Water Resistant Power Cable.

Goulds Water Technology Pumps 2AM32 Self Priming, Air Cooled Gasoline Engine Driven Pump with Cast iron, open-impeller models for dewatering applications. The 2AM32P Petro-Guard Self-Priming Petroleum Product Pump is specifically designed for pumping petroleum products such as diesel and Jet fuel and gasoline when in a well ventilated area where lack of electric power makes it impossible to use pumps driven by explosion proof electric motors.

Goulds Water Technology Pump Replacement Motors - Includes many series such as the S-Group, M-Group, e-SV, MPVN, GB, 45HB and 70HB. Various enclosure types and frame sizes with many Baldor options.

Smart, Connected, All‑in‑One Pressure Boosting

Introducing the AquaCase™ by Goulds Water Technology—a next‑generation pressure boosting system engineered to deliver steady, reliable water pressure for residential and light commercial applications. With built‑in Wi‑Fi and Bluetooth®, AquaCase connects to a free mobile app, giving users effortless remote monitoring and control from anywhere.

Its compact, all‑in‑one design integrates a variable speed pump, motor, pressure sensor, tank, and intelligent controller into a single, streamlined unit. The result is faster installation, greater efficiency, and consistently dependable performance.

AquaCase brings smarter water pressure management to every installation.

The AquaCase Advantage

AquaCase delivers a cost‑effective solution for homes and properties dealing with low municipal water pressure, and it’s equally effective for boosting pressure from a storage tank. As water usage fluctuates throughout the day, the system automatically adjusts motor speed to match demand, ensuring consistent, reliable pressure whenever you need it.

Product Features

Energy efficient: Variable frequency drive (VFD) technology automatically adjusts pump speed to maintain steady pressure while reducing energy consumption.

Wireless access: Built‑in Bluetooth® and Wi‑Fi provide remote monitoring and control through a free smartphone app.

Versatile application: A single system designed for residential, light commercial, and irrigation use—eliminating the need for multiple product lines.

Dual‑voltage ready: Supports both 115V and 230V installations, simplifying selection and stocking.

Quiet performance: Advanced hydraulic design minimizes noise for a smoother, quieter operation.

Fast installation: MNPT inlet and discharge connections are engineered for straightforward setup and reduced installation time.

Dual‑seal protection: Primary and secondary mechanical seals work together to reduce leakage and extend system longevity.

Rugged enclosure: UL Type 3R (NEMA 3R) housing shields the integrated system for reliable indoor or outdoor use.

Upgradable software: Add new features and performance enhancements in the field—no need to remove the unit from service.

Built‑in electrical safeguards: Integrated protection defends against over‑current, incorrect voltage, short circuits, and other electrical issues.

The AC10 model operates on either 115V or 230V, offering flexibility for different installation requirements. At 115V, it delivers 10 GPM at 56 PSI (37.8 L/min at 3.86 BAR) with a maximum flow of 30 GPM (113.5 L/min). At 230V, it provides 20 GPM at 50 PSI (75.7 L/min at 3.45 BAR) with a maximum flow of 38 GPM (143.8 L/min). The system supports a maximum setpoint of 80 PSI and requires a 15A breaker for both voltage configurations.

e-AB3 Smart Pump Range Packaged Pumping System

e-HME Integrated Variable Speed Constant Pressure Systems

1/2 HP, 3/4 HP, 1 HP & 2 HP Model Configurations

Models:

• 1AB31HME04
• 1AB31HME06
• 1AB35HME03
• 2AB310HME02
• 2AB33HME08
• 2AB35HME05
• 2AB35HME06


Boosting pressures and energy reductions equal to that of the e-AB2 plus

Ultra-premium Efficiency: Features the Xylem Smart Motor, an ultra-premium IE5 permanent magnet motor and provides: - Efficiency well above a standard IE3 NEMA premium efficient asynchronous induction motor - Average of 15% in energy savings when compared to similar pumps in the market

Easy to Install: Includes a complete kit for installation: pump, Smart Motor, gauge, tank and tee › Programmed to motor electrical characteristics; just select “set pressure”

Quiet operation: High efficiency hydraulics, motor and thick metal pump body keep the noise level to a minimum

e-AB3 Features

The e-AB3 smart pump range packaged pumping system is a constant pressure booster system that is specifically designed for customers of municipal water districts with low water pressure, or those seeking a boost from a local storage tank. Featuring the e-HM pump and the Xylem Smart Motor, an ultra-premium IE5 permanent, magnet motor, the e-AB3 provides pumping efficiency well above a standard IE3 NEMA premium efficient asynchronous induction motor.

As water flows to your house, it loses some of its pressure to friction inside the pipe. The higher the flow, the more the friction reduces your water pressure. This flow increase can be caused by more homes and businesses on your water main, the size of your home piping system or increased water use in your house. As water use increases, the e-AB3 changes pump speed to keep line pressure constant. Large supply tanks are eliminated and up to 50% of the energy required by a full speed pump is saved. The e-AB3 is available with a range of flow rates to handle residential homes, irrigation systems, and office buildings. It’s a HIGH PERFORMANCE solution for both residential and commercial customers who need to increase their water pressure when water demand is high.

Pump Protection: safety and monitoring

The Smart Motor comes with a wide range of monitoring, control and safety features right out of the box with no need to configure.

In addition to these regulation functions, the Smart Motor also:

• Controls, safety features and monitoring tools
• Stops the pump at zero demand
• Stops the pump in case of water failure
• Has failure and over-temperature sensors for both the inverter and motor, which protects the pump and motor from under or over-voltage

Available control modes include:

• Control for constant pressure
• Control to match a system curve
• Control according to an external signalT

The Smart Motor offers a complete set of supervision and metering tools such as automatic test starts, auto smart cyclic change of lead and lag pump units, a memory for any inverter fault signals, and an operating-hours run counter. There’s no need to configure the product; all the listed features are already included in the standard package.

Goulds Water Technology Cast Iron GEP Pump Applications

Specifically Built and Designed to Drain Basements, Water Transfer, Filtered Effluent and Dewatering

GEP Features Include:

1. Reliable mechanical switch coupled with solid float for dependable performance
2. Oil-cooled motor permanently lubricated for extended service life and is powered for continuous operation
3. Premium mechanical seal design provides superior protection against sand and abrasive damage (Silicon Carbide/Silicon Carbide/BUNA)
4. Vortex impeller can handle solids up to 3/4" in size
5. Cast iron motor housing for optimal heat dissipation
6. Corrosion resistant hardware for lifetime use
7. Cast iron base
8. Built-in vent hole prevents air-binding with no added labor
9. Available in automatic and manual models
10. Approved for residential use (CSA/CUS Listed)
11. Three year warranty

Pump Specifications GEP Series

• Discharge Size: 1 ½" NPT
• Capacities: to 85 Gallons Per Minute (GPM)
• Maximum Head: 45 Foot TDH
• Maximum Solids Handling: 3/4" Spherical
• Impeller: Vortex
• Temperature: 104º F (40º C)
• Mechanical Seal: Silicon Carbide/Silicon Carbide BUNA

GEP Motor Information

• 1/2 HP & 3/4 HP, 115 & 230V, 60 Hz, Single Phase (1PH), 1750 RPM
• Automatic vertical float, manual float switch option
• Built-in Thermal Overload Protection
• Oil Filled Design
• 10', 20' and 30' Models Available. All models have NEMA three prong grounding plugs.

Goulds Water Technology ResiBoost Complete Packaged Variable Frequency System

Complete Packaged Residential Constant Pressure Boosing System for the way you live

The Resi-Boost Advantage

Xylems' ResiBoost constant pressure system provides an economical solution for municipal water users that suffer from low pressure. In addition the ResiBoost constant pressure system can also be used for applications requiring repressurizing water from a storage tank. As your household water needs change, our drive will change the speed of the motor to accomodate the need.

ResiBoost Features

Powered for Continuous Operation: All ratings are within the working limits of the motor as recommended by the motor manufacturer. Pump can be operated continuously without damage to the motor.

Built-in Check Valve: Completely assembled ResiBoost includes a uniquely designed fit including a spring loaded check valve.

Built-in Memory: Stored data - operating hours, number of starts, connection to the power supply, faults.

VFD: Built-in protection against various system and electrical faults. Comes with internal transducer with digital indicator, additional parts not necessary. Pre-wired to e-HM pump.

Electrical Protection: Protects against over incorrect power supply, and short circuit.

Display: Control with LCD display and simple push button settings.

Energy Savings: Precise speed control to operate pump for best energy efficiency.

Stainless Steel Pump: e-HM series stainless steel pump with small footprint designed for longer life.

Ease of installation: Complete system with pump, motor and controller assembled. Tank included seperate from assembly for shipping. Plug and Play compact system.

Offerings: Six SKU's to cover all residential boosting applications up to 35 GPM.

ResiBoost Controller Features

• Input Power: Single Phase 115 and 230 V
• Output Power: Single Phase 115 and 230 V, 3 phase 230 V
• Programming: Pre-programmed
• Input Controls: HMI with push button control
• Signal Lights: Red LED
• Protection Against: No Water, Motor Over Current, Open Lead, Low System Pressure, Over Heating, Short Circuit, Over Voltage, Under Voltage
• Temperature Rating: 32º - 122ºF
• Approvals: CCSAUS, NSF
• Enclosure: Type 3
• Power Lead: 230V plug (NEMA 6-20) on 230 V, 115 V plug (NEMA 5-15) on 115 V selections

DELIVERING MAXIMUM COMFORT: Customers are able to enjoy improved water pressure consistently regardless of the number of fixtures in use or the location of the fixture in the home. Designed to operate quieter than a conventional pump system.

PROVIDING LASTING PERFORMANCE: The ResiBoost is proven to last in the most demanding of boosting conditions, customers can rest easy rather than worry about downtime or service needs.

SIMPLIFYING INSTALLATIONS: The plug and play system comes with the pump, motor and controller already assembled and fully programmed (tank included but not installed). An integral transducer instantly reduces the number of parts required for installation. The small-but-powerful design of the ResiBoost system allows for a variety of installation locations, including a small utility closet. Uniquely designed union with check valve eliminates separate assembly

Goulds Water Technology GSP0511 Cast Iron Sump and Effluent Pump

• Premium quality pump to keep your basement dry
• Reliable Mechanical switch coupled with solid float for dependable performance
• Cast Iron Motor Housing allowing for optimal heat dissipation
• Approved for Residential use (CSA/CUS Listed).
• Premium Mechanical Seal design provides superior protection against sand and abrasive damage (Silicon Carbide/Carbon/BUNA)
• Engineered motor designed for peak hydraulic performance without overloading.
• Suction Strainer encompasses entire base – designed to reduce debris entry
• Corrosion resistant hardware for lifetime use
• 2 year warranty

VTX Series Vortex Sewage Pump by Goulds Water Technology

Goulds Water Technology, a Xylem brand, is proud to Introduce a tough, submersible, durable new line of sewage pumps with all the benefits that you expect from Goulds Water Technology. They’re top-quality, high-performance products, proudly built in the USA by a company that leads the industry in innovation and service. The new GWT Vortex Pump is field serviceable, with a dry cap that makes it easy to replace the capacitor in the field. This vortex pump handles stringy material and resists clogging better than a traditionaltwo-vane impeller.

• Impeller: Cast iron, multivane, vortex style.
• Casing: Cast iron volute for maximum efficiency.
• Mechanical Seal: Silicon carbide sealing faces for superior abrasive resistance.
• Shaft: Corrosion-resistant, 300 series stainless steel with a threaded design.
• Fasteners: 300 series stainless steel.
• Capacitor Compartment: Oil free, making it easy to replace the capacitor in the field.

Specifications

• Solids handling capabilities: 2” maximum
• Capacities: Up to 208 GPM
• Total heads: Up to 66 feet TDH
• Discharge size: 2” NPT threaded as standard
• Temperature: 104°F (40°C) continuous, 140°F (60°C) intermittent Class B insulation
• Single phase (60 Hz): PSC motors for maximum starting torque, Built-in overload with automatic reset SJTOW severe duty oil and water resistant power cords, 20’ length & ½ – 2 HP models have NEMA three prong grounding plugs.
• AGENCY LISTINGS: USC®, Tested to UL 778 and CSA 22.2 108 standards By Canadian Standards Association File #LR38549

Submersible VTX Models:

• VTX0511 - 0.5HP 115V 1Phase 12.5 MA
• VTX0512 - 0.5HP 230V 1Phase 7.7 MA
• VTX1012 - 1.0HP 230V 1Phase 9.5 MA
• VTX1512 - 1.5HP 230V 1Phase 13.0 MA
• VTX2012 - 2.0HP 230V 1Phase 16.0 MA

Applications - Designed specifically for the following uses:

• Homes
• Water Transter
• Sewage Systems
• Light Industrial
• Dewatering / Effluent
• Commercial Applications
• Anywhere waste or drainage must be disposed of quickly, quietly and efficiently.

Goulds Water Technology CentriPro Wastewater Accessories, a Xylem brand. If you need any and all Goulds Water Technology wastewater pump accessories you will find them here. We have many accessories available including: Junction boxes, Basin Kits, Elbows and all sorts of Lifting Cables, Chains & Pump Bails. There are also many control panels with options and level alarms for simplex and duplex control panels. Looking for Guide Rails and Disconnect Systems? Look no further... we can supply you with all sorts of guide rail assemblies, rail systems and adapters.

If you need Float Switches and Mounting Brackets, we have everything you could need for your system. We also carry replacement motors and control repair parts for all wastewater pumps and parts for SES Controls. If you have any questions please don't hesitate to give us a call and we can make sure you are ordering the right wastewater accessories for your pumping application.
